主要用途
適用于將根莖類藥材如甘草、黃芪等藥材加工成瓜子片。

Main uses
Apply to the rhizome medicinal herbs such as Radix Glycyrrhi2ae. Radix Astragali etc. processed seeds tablets.

主要特點
結構合理、便于操作、刀片易裝卸、便于清理等特點，是中藥飲片行業實現斜片切制的理想設備.

Main technical characteristics
The machine is well-structured, and it is easy to install and remove the knives. Thus it is the ideal oblique piece-cutting machine.

主要技術參數 Main technical parameter

型號 Type	生產能力 Capacity (kg/h)	出料口尺寸 herb outlet door size (mm)	切片厚度 Slice thickness (mm)	電機功率 motor (KW)	外形尺寸 dimension (mm)	整機重量 weight (kg)
QYX-400	100-200	85x80	2-3	2.2+0.75	1460x745x1096	550
